| Quantity: | |
|---|---|
Brand Information
| Brand Name | BAFFERO |
| Experience | 35+Years |
| MOQ | 1 Set |
| Delivery Time | 25 Days |
| Warranty Time | 12 Months |
| Certification | CE/ ISO9001/ BV/ SGS |
| Supply Ability | 10000 Pcs per a month |
| Shipping Port | Shanghai or Ningbo |
| Place of Origin | China |
Gearbox Information
| Product Name | DP Series Right Angle Planetary Gearbox |
| Model Number | DP2L9~DP2L36/ DP2K9~DP2K36/ DP3K9~DP3K36 |
| Gear Precision | DIN6 (ISO1328) |
Gear Arrangement | Planetary gear |
Gearbox Casing Material | Cast Iron |
Gear Material | 20CrMnTi |
Gear Hardness | HRC58 ~62 |
| Noise Level | 65~75DB |
Shaft | 40Cr and 20CrMnTi |
Color | As requirement |
Gear Heat treatment Processing | Carburizing and Quenching |
Features of DP Series Planetary Gear Motor
High modular design.
Compact design and dimension, light weight.
Wide range of ratio, high efficiency, stable running and low noise level.
Several planet wheels run with load at the same time and distribute the power to realize the combination and separation of moving.
Realize the coaxial transmission easily.
Rich optional accessories.
DP Series Planetary Speed Reducer Design
Planetary stage: 2 stage or 3 stage.
Input mode: N standard (coaxial mode), S 1st stage helical gear shaft, L 1st bevel gear shaft, K 1st bevel-helical gear shaft.
Output mode: solid shaft (with key, with involute splines), hollow shaft (with shrink disc, with involute splines).
DP Series Planetary Gearbox Widely Used In:
Belt conveyor drives
Bucket elevator drives
Agitator drives
Hoisting gear drives
Travelling gear drives
Paper machine drives
Dryer drives
Water screw drives
DP Series Right Angle Planetary Gearbox - FAQ
The DP Series Right Angle Planetary Gearbox is designed for heavy-duty industrial applications requiring extremely high torque, compact installation space, and reliable power transmission. Compared with N series planetary gearboxes, the DP series offers larger load capacity and higher output torque, making it suitable for mining, material handling, steel processing, cement plants, and large conveyor systems.
1. When should I choose DP series instead of N series planetary gearboxes?
If your required output torque exceeds 100,000 N.m, or your equipment operates under extremely heavy loads, the DP series is generally a better choice.
2. What should I do if I don't know which model of reducer I need？
Contact us and provide the following information：
Motor power
Output speed
Torque requirement
Installation type
Application industry
Housing color
Purchase quantity
Our engineers will recommend the suitable model for you within 2 hours.
3. What cooling options are available?
Optional cooling methods include:
Cooling fan
Cooling coil
Water cooling system
External cooling unit
4. What are the available installation add-on piece？
Gear housing base
Motor bracket
Motor swing bracket
Torque reaction arm
Torsion shaft support
Need a Reliable DP Gearbox Supplier?
Zhejiang Baffero provides:
35+ years manufacturing experience
ISO9001 & CE certified production
OEM & non-standard gearbox customization
Fast quotation within 24 hours
Export experience to global markets
Contact us now for technical support and quotation.
