| Quantity: | |
|---|---|
Brand Information
| Brand Name | BAFFERO |
| MOQ | 1 Set |
| Delivery Time | 25 Days |
| Warranty Time | 12 Months |
| Certification | CE/ ISO9001/ BV/ SGS |
| Shipping Port | Shanghai or Ningbo |
Place of Origin | China |
Gearbox Information
| Product Name | Parallel shaft helical gear reducer |
| Model Number | F37- F157 |
Output Speed | 0.16-1028 r/min |
Rated Power | 0.18-200KW |
Output Torque | 200~18000N.m |
Gear Type | Helical |
Ratio | 3.81 - 198.14 |
Gear Precision Level | DIN6 |
Housing Material | HT200/ HT250 high-strength cast iron |
Gear Material | 20CrMnTi |
Input / Output Shaft Material | 40Cr |
Input Power and Torque (MAX)
Size | 37 | 47 | 57 | 67 | 77 | 87 | 97 | 107 | 127 | 157 |
Structure | F FA FF FAF FAZ | |||||||||
Input power rating (kw) | 0.183 | 0.18-3 | 0.18-5.5 | 0.37-5.5 | 0.18-11 | 0.75-22 | 1.1-30 | 2.2-45 | 7.5-90 | 11-200 |
(Ratio) | 3.81-128.51 | 5.06-170.27 | 5.18-199.70 | 4.21-196.46 | 4.20-243.46 | 4.12-270.68 | 4.68-270.64 | 6.20-255.25 | 4.63-172.33 | 12.07-198.14 |
Max torque (N.m) | 200 | 400 | 600 | 820 | 1500 | 3000 | 4300 | 7840 | 12000 | 18000 |
Gear Unit Weight
| Size | 37 | 47 | 57 | 67 | 77 | 87 | 97 | 107 | 127 | 157 |
| Weight (KG) | 12 | 18 | 34 | 55 | 90 | 150 | 260 | 402 | 700 | 950 |
Main Options
Backstop
Low backlash type
Lateral holes for side mounting
Gearbox Features
High mounting flexibility
Minimized installation space requirements
Sturdy and durable construction
Reduced standard backlash
High dynamic performance and energy-saving solution
Wide selection range of output speeds
Can be combined with R series, K series, S series, etc., to achieve lower speeds and greater torque
Average efficiency: 96% for 2-stage, 94% for 3-stage, and 85% for combined types
Application Fields： Available with reduced backlash, particularly suited for material handling and process engineering applications. This parallel hollow shaft helical gearmotor is designed and produced for mixers, conveyors, belts, industrial and port lifting equipment. The gears are made of high wear resisting alloy materials, specially treated and finely processed.
About Us
Zhejiang BAFFERO Driving Equipment Co., ltd is an enterprise specialized in producing reducers, integrating scientific research and development, production and trade. The main products include planetary gear reducers, industrial gearboxes, R, K, F, S series gear boxes, lifers, etc. The products are widely applied in industries as metallurgy industry, mining industry, hoisting and conveying industry, engineering environmental protection industry, petrochemical industry, rubber & plastics industry, food packing industry, etc.
Over more than 34 years, by holding the concept of human oriented and scientific innovation, we have always been devoted to talent storing and research and development of new products, continuously invested in research and development, striving to provide first-class transmission equipment for customers. With outstanding quality, all products bearing the mark of BAFFERO have become the first choice of customers and have been sold far to Europe, America, Southeast Asia, etc.
FAQ
1. How to choose a speed reducer which meets our requirement?
You can refer to our catalogue to choose the gearbox or we can help to choose when you provide the technical information of required output torque, output speed and motor parameter, etc.
2. What information shall we give before placing a purchase order?
a. Type of the gearbox, ratio, input and output type, input flange, mounting position and motor information.
b. Housing color
c. Purchase quantity
d. Other special requirements.
3. What industries are your gearboxes being used?
Our transmission gearboxes are widely used in the areas of textile, food processing, beverage, chemical industry, escalater, automatic storage equipment, metallurgy, tobacco, environment protection, logistics and etc.
4. Do you sell motor together?
Yes, but we don’t manufacture motor, we have several stable motor suppliers who have been cooperating with us for long time, they provide us high quality motors.
