Power: 0.18~120KW
Torque: 70~20000N.m
Connection: Flange, Shaft, Motor
Mounting: Flange mounted, Foot mounted
Certification: CE/ ISO9001/BV/SGS
| Quantity: | |
|---|---|
Running your hand along the cool, densely cast housing of the Cycloid Small Planetary Gear Reducer, you can immediately sense the industrial-grade durability engineered into its core. Designed to anchor the most demanding mechanical systems, this drive unit translates raw motor energy into controlled, unyielding torque. By eliminating the concentrated stress points found in standard gear designs, it protects your critical machinery from sudden mechanical failures. Whether your operations involve heavy material lifting, continuous mixing of viscous fluids, or precise automated positioning, this reducer ensures your production lines maintain a steady, uninterrupted rhythm without the constant need for component replacements.
| Brand Name | BAFFERO |
|---|---|
| Experience | 35+Years |
| MOQ | 1 Set |
| Delivery Time | 25 Days |
| Warranty Time | 12 Months |
| Certification | CE/ ISO9001/ BV/ SGS |
| Shipping Port | Shanghai or Ningbo |
| Place of Origin | China |
| Product Name | Cycloidal Gear Motor |
|---|---|
| Model Number | X2~X11 |
| Torque | 70 Nm to 20,000 Nm |
| Input Power | 0.18 to 120KW |
| Ratios | 9~87 (single) 121~5133 (double) |
| Gear Precision Grade | 6(ISO 1328) |
| Gear Surface Hardness | HRC58-62 |
| Gear Material | 20CrMnTi |
| Shaft Material | 40Cr |
| Housing Material | Main aluminium alloy ;Cast iron |
| Bearing Brand | HRB ;NSK;SKF |
| Packing | Standard export packing |
| Color | Blue; Gray |
| Model | X2 | X3 | X4 | X5 | X6 | X7 | X8 | X9 | X10 | X11 |
|---|---|---|---|---|---|---|---|---|---|---|
| Torque (N.m) | 150 | 250 | 500 | 1000 | 2000 | 2700 | 4500 | 7100 | 12000 | 20000 |
Conveyors: Maintaining steady material flow across long distances without stalling under sudden weight shifts.
Mixers and Agitators: Providing the consistent, high-torque rotation required for blending thick, viscous chemical or food compounds.
Mining Equipment: Enduring heavy vibrations and abrasive dust environments while driving crushers and feeders.
Metallurgy Industry: Operating reliably in extreme heat and continuous heavy-load processing lines.
Cement Machinery: Driving kilns and mills where extreme torque and dust resistance are mandatory.
Food Processing Machines: Ensuring hygienic, fluid motion that prevents product damage during automated handling.
Packaging Equipment: Delivering precise synchronization for high-speed wrapping and boxing lines.
Textile Machinery: Offering smooth, vibration-free operation to prevent thread breakage.
Chemical Industry Equipment: Resisting corrosive atmospheres while powering critical reactor agitators.
Environmental Protection Equipment: Driving wastewater clarifiers and sludge thickeners with unyielding reliability.
BAFFERO Cycloidal gear reducers, speed reducers, and gearmotors stand as the premier choice for in-line drives. The core working principle revolves around a specialized multi-tooth simultaneous meshing mechanism. Instead of the traditional involute tooth profile that relies on minimal contact points, our cycloidal wheel incorporates a curved tooth profile. This internal structure ensures that a large portion of the teeth are engaged at any given moment, distributing the physical load evenly across a massive contact area. This design completely removes shear forces at any point of contact, transforming what would be a harsh grinding action into a smooth, rolling motion. The result is exceptionally low wear, high resistance to sudden impacts, and a suite of performance benefits that keep your production running smoothly.
Achieve massive speed reductions without needing bulky, multi-stage gear trains. A 1-stage reduction ratio reaches up to 1:87, while 2-stage combinations are available for larger ratios up to 5311:1. Despite these extreme ratios, the rolling contact design ensures that transmission efficiency exceeds 90%, minimizing energy waste and lowering your facility's power consumption.
Space on a factory floor is always at a premium. The coaxial input and output shaft structure allows the motor and gearbox to align perfectly on a single axis. This creates a remarkably small footprint with high torque density, ensuring easy integration into various machinery systems without requiring expensive structural modifications to your equipment.
Stand next to this gearbox in operation, and you will notice a distinct lack of the harsh metallic clanking typical of standard drives. The multi-tooth meshing design dramatically reduces vibration, resulting in stable transmission performance and a lower operating noise that improves the working environment on the production floor.
Engineered specifically for extreme condition adaptability, this unit thrives where others fail. It offers excellent shock resistance and overload capability, making it the definitive choice for Mission Critical Machinery. Whether facing frequent start-stop applications, sudden heavy shock loads, or strong overhung load performance requirements, the cycloidal mechanism absorbs the punishment without fracturing.
Built from high-strength alloy steel components, the internal mechanics are designed to outlast the equipment they drive. The hardened gear surfaces (HRC58–62) resist pitting and wear over years of continuous use. The durable rolling contact transmission design means friction is virtually eliminated, extending the operational lifespan far beyond conventional alternatives.
Downtime costs money. That is why this unit features a simple structure with fewer components than complex helical-bevel arrangements. It offers convenient installation and disassembly, allowing your maintenance crews to perform routine checks quickly. The low maintenance requirements mean your team spends less time wrenching and more time producing.
The X Series Cycloidal Gear Reducer is designed for demanding industrial applications requiring high torque, compact structure, and exceptional durability. Utilizing advanced cycloidal pin-wheel transmission technology, this gearbox delivers high reduction ratios, outstanding shock load resistance, and reliable long-term performance. When engineers consult our selection guide to compare planetary gears with cycloidal reducers, the differences become clear: while planetary units offer compactness, cycloidal reducers provide vastly superior overload capacity, smoother transmission, and longer service life under heavy-duty working conditions. The compact coaxial design also helps save installation space while maintaining high efficiency and stable operation, effectively reducing long-term maintenance costs.
35+ years manufacturing experience: Decades of refining our casting and machining processes ensure every unit performs to exact specifications.
OEM customized gearbox solutions: We tailor the internal gearing and external housings to fit your exact operational parameters.
Strict quality control and testing: Every unit undergoes rigorous load and acoustic testing before leaving our facility.
Stable performance with competitive pricing: Achieve premium industrial reliability without exceeding your procurement budget.
Fast delivery and global export support: We ensure rapid technical response and global spare parts delivery to keep your operations running.
CE ISO certified manufacturer: Documented compliance with strict international industrial standards.
Lifecycle after-sales and maintenance: Beyond our own products, our technical teams possess the capability to service, repair, and maintain other leading brands of cycloidal reducers.
BAFFERO supports customized solutions based on customer requirements, focusing heavily on brand compatibility and drop-in replacement strategies. Options include:
Special reduction ratios: Engineered to match your exact speed requirements.
Different motor brands: Seamless integration with your preferred servo or induction motors.
Custom shaft dimensions: Tailored to fit your existing couplings and driven equipment.
Special mounting configurations: Installation dimensions engineered to seamlessly replace international mainstream premium brands, allowing for highly cost-effective complete machine replacements.
Heavy-duty reinforced designs: Upgraded bearings and seals for highly corrosive or abrasive environments.
Custom color and branding: Matching your corporate identity or specific facility safety color codes.
Looking for a reliable cycloidal gear reducer manufacturer?
BAFFERO provides premium gearbox solutions with competitive pricing and professional technical support. Contact us now for catalogs, drawings, pricing, and customized solutions tailored to your facility's unique demands.
Zhejiang Baffero is a leading manufacturer specializing in high-performance power transmission solutions. Based in Zhejiang, China, we integrate R&D, precision manufacturing, and global sales to provide heavy-duty industrial gearboxes. Walking through our facility, you will hear the precise hum of advanced CNC machinery shaping raw steel into exact tolerances, surrounded by the clean scent of industrial lubricants. Our core expertise lies in HB Series high-power gearboxes, P / N Series planetary units, and R/K/F/S modular geared motors. Beyond supplying individual components, we excel in providing one-stop transmission solutions. This means we support packaged procurement of multiple gearbox categories, exact servo motor matching, and complete drive assembly customization for non-standard automated equipment. Utilizing advanced CNC technology and modular design, we deliver reliable, efficient, and cost-competitive drive solutions for demanding industries such as mining, material handling, and automation worldwide.
