BRAND INFORMATIOM
| Brand | BAFFERO |
Model | R37...167/ RX31-151 |
Certification | CE / SGS / BV |
Place of Origin | CHINA |
QUICK DETAILS
| Gearing Arrangement | Helical |
Output Torque | UP TO 18000N.m |
Rated Power | 0.18-160kw |
Input Speed | Less than 2000r/min |
Output Speed | 0.16-1028r/min |
Ratio | 1.3 - 196.41 |
Material of housing | Cast Iron |
Material of gear | 20CrMnTi with grinding |
Material of shaft | 40Cr with carburizing and quenching |
Mounting Type | Foot mounted, Flange mounted |
Input form | IEC input flange, direct with motor, shaft input |
Color | Blue RAL5010, Grey or other |
Warranty | 12 Months |
Supply Ability | 5000 Sets per Month |
YOUR BENEFITS
High power density
Long service life
R37 to R167 reduced backlash option
RM series, specially designed for agitating applications
The tried and tested modular concept and our strict quality criteria allow BAFFERO to provide a diverse range of torques and gear ratios with incomparably finely tuned grading. With this exceptional diversity, BAFFERO sets new standards in the field of drive engineering
AVAILABLE VERSIONS
Single-stage or multi-stage
Foot-mounted or flange-mounted
Foot-mounted and flange-mounted
Flange-mounted with extended bearing hub
Transmission Efficiency: 2 stage (ratio: 5-24.8) = 96%
3 stage (Ratio: 27.2-264) = 94%
PACKAGING & DELIVERY
Packaging Details: Standard export plywood case
Port: Ningbo / Shanghai
Lead Time:
Quantity(Sets) | 1 - 2000 | >2000 |
Est. Time(days) | 25 | To be negotiated |
